DFB1412PTV DFB1412PTV-I

12 needle, flat bed, double chain stitch machine for pintucking with rear puller
*PTV-I is model for invisible seaming
    DFB1412PTV DFB1412PTV-I
    Max speed 3500rpm 3000rpm
    Needle Type #DV X 57 12
    Stitch Length 7~17/inch
    Presser Foot Lift 10mm
    Needle Bar Stroke 34mm
    Diff.Feed Ratio –
    Gauge Size 3/16,1/4 3/16-6mm,1/4-8mm
  • 3/16” 6needle 2mm Left Pin tacking width (2mm, 5mm, 8mm) Left or right fold selection

    3/16” 6needle 2mm Left
    Pin tacking width (2mm, 5mm, 8mm) Left or right fold selection

  • 3/16” 6needle 2mm Left

    3/16” 6needle 2mm Left

  • 3/8” 6needle 8mm Left (3/16” 12needle)

    3/8” 6needle 8mm Left (3/16” 12needle)

  • 3/16” 12needle 2mm Left & Right

    3/16” 12needle 2mm Left & Right

  • 3/8” 6needle 11mm Right (3/16” 12needle) Pin tucking width (6mm, 8mm, 11mm, 14mm) left side fold

    3/8” 6needle 11mm Right (3/16” 12needle)
    Pin tucking width (6mm, 8mm, 11mm, 14mm) left side fold
